07 Misc. Metals-Flood Control, Storm Drains, Storm Sewer
SPPWC 150-4 CURB DRAIN, CASE I AND II
CASE I and CASE II HINGED COVER and FRAME and SLOTTED DROP INLET for transition from R/W to curb and gutter
Cast iron. SPPWC 152-3 rectangular hinged cover and frame for CASE I applications (SPPWC Standard Plan 152-3 for Type 1 Hinged Access Frame and Cover)
| Catalog Number | Overall Height | Clear Opening | Approximate Weight |
|---|---|---|---|
| CASE I INLET | 2-1/4"" | 12"" | 43 lbs |
| CASE II INLET | 1-1/2"" | 13"" | 40 lbs |
CASE I available painted black (LB 2273A) or hot dipped galvanized (LB 2273B)
